Collision detection

Overview

When you drag something over a droppable target, dnd kit runs a collision detection algorithm to decide which target is currently being hovered. The default works well for most lists, but you can customize it per droppable when you need different behavior — for example, card stacks, grids, or nested containers.

Built-in detectors are exported from the @dnd-kit/collision package. You don’t need to install it explicitly — it’s already a transitive dependency of @dnd-kit/react.

Built-in detectors

defaultCollisionDetection

The default. Runs pointerIntersection first, and falls back to shapeIntersection when the pointer isn’t inside any droppable.

pointerIntersection

High precision — a collision is only detected when the pointer is inside the droppable’s bounding rectangle. Good for precise drop zones where you want the user to clearly be “over” a target.

shapeIntersection

Returns the droppable with the greatest overlap area with the dragged element’s shape. Good for large containers where any visual overlap should count as a collision. Ties are broken by distance to the pointer.

closestCenter

Picks the droppable whose center point is closest to the dragged element’s center. Ideal for card stacking or grids where items snap to the nearest slot.

closestCorners

Picks the droppable with the smallest average corner-to-corner distance. More forgiving than closestCenter at the edges of a list — useful for vertical sortable lists where you want items to pick up a neighbor as soon as the corners approach.

pointerDistance

Returns the droppable whose center is closest to the pointer coordinates (not the dragged element). Useful when you want drop detection to follow the cursor rather than the dragged element.

directionBiased

Only detects collisions in the direction the user is dragging (up, down, left, right). Useful when you want items to only be swapped when the user drags toward them — prevents jitter when hovering near the edge between two targets.

Configuring a detector

The collisionDetector option is set per droppable. Pass any built-in detector (or a custom one) to useDroppable or useSortable:

import {useDroppable} from '@dnd-kit/react';
import {closestCenter} from '@dnd-kit/collision';

function DropTarget({id}) {
  const {ref, isDropTarget} = useDroppable({
    id,
    collisionDetector: closestCenter,
  });

  return <div ref={ref}>{isDropTarget ? 'Drop here' : 'Empty'}</div>;
}

The same option works on useSortable:

import {useSortable} from '@dnd-kit/react/sortable';
import {closestCorners} from '@dnd-kit/collision';

function SortableItem({id, index}) {
  const sortable = useSortable({
    id,
    index,
    collisionDetector: closestCorners,
  });

  return <div ref={sortable.ref}>Item {id}</div>;
}

Collision priority

When multiple droppables overlap — for example, a sortable card inside a droppable column — you can bias which one “wins” using collisionPriority. Higher values take precedence.

import {useDroppable} from '@dnd-kit/react';
import {CollisionPriority} from '@dnd-kit/abstract';

function Column({id, children}) {
  const {ref} = useDroppable({
    id,
    collisionPriority: CollisionPriority.Low, // Cards inside will win by default
  });

  return <div ref={ref}>{children}</div>;
}

The CollisionPriority enum is exported from @dnd-kit/abstract and provides named levels: Lowest, Low, Normal, High, Highest. You can also pass a plain number.

Writing a custom detector

A collision detector is a function that receives the drag operation and a droppable, and returns a collision (or null if there’s no collision). The return value is a score — higher scores win when multiple droppables collide.

import type {CollisionDetector} from '@dnd-kit/abstract';
import {CollisionPriority, CollisionType} from '@dnd-kit/abstract';

const myDetector: CollisionDetector = ({dragOperation, droppable}) => {
  if (!droppable.shape) return null;

  // Your logic here — return null for no collision, or an object:
  return {
    id: droppable.id,
    value: 1, // Higher values win
    type: CollisionType.Collision,
    priority: CollisionPriority.Normal,
  };
};

Pass it to any droppable:

useDroppable({id, collisionDetector: myDetector});

For reference implementations, read the source of the built-in detectors in @dnd-kit/collision.

If you’re coming from @dnd-kit/core, see the Migration guide for legacy API mappings.
